Leírás és Paraméterek
| CAMERA | |||
| Image Sensor | 1/2.7” Progressive Scan CMOS | ||
| Shutter Speed | 1/3 to 1/10000 s | ||
| Slow Shutter | Yes | ||
| Minimum Illumination | 0.005 Lux; 0 Lux with IR/White light | ||
| Day/Night Mechanism | IR Cut Filter | ||
| Day/Night Switch | Unified/ Scheduled/ Auto | ||
| LENS | |||
| Type | Fixed Focal Lens | ||
| Focal Length | 2.8/4 mm | ||
| Aperture | F1.6 | ||
| FOV | • 2.8 mm: | ||
| Horizontal FOV: 100°, Vertical FOV: 54°, Diagonal FOV: 118° | |||
| • 4 mm: | |||
| Horizontal FOV: 80.4°, Vertical FOV: 41.8°, Diagonal FOV: 98.7° | |||
| Lens Mount | M12*P 0.5 | ||
| DORI Distance | • 2.8 mm | ||
| Detect: 64 m (210 ft) | |||
| Observe: 27 m (89 ft) | |||
| Recognize: 13 m (43 ft) | |||
| Identify: 6 m (20 ft) | |||
| • 4 mm | |||
| Detect: 80 m (262 ft) | |||
| Observe: 33 m (108 ft) | |||
| Recognize: 16 m (52 ft) | |||
| Identify: 8 m (26 ft) | |||
| Angle Adjustment (Manual) | |||
| Range | Pan: 0° to 360°, Tilt: 0° to 85°, Rotation: 0° to 360° | ||
| ILLUMINATOR | |||
| IR LED | • Quantity: 4 | ||
| • Range: 30m | |||
| • Wavelength: 850nm | |||
| White LED | • Quantity: 4 | ||
| • Range: 30m | |||
| Illuminator On/Off Control | Auto/Scheduled/Always on/Always off | ||
| VIDEO | |||
| Max. Resolution | 2688 x 1520 | ||
| Main Stream | • Frame Rate: | ||
| 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps | |||
| 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps | |||
| • Resolution: | |||
| 2688x1520, 2560x1440, 2304x1296, 2048x1280, 1920x1080, 1280x720 | |||
| Note: | |||
| • If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. | |||
| Sub-Stream | • Frame Rate: | ||
| 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps | |||
| 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps | |||
| • Resolution: | |||
| 848x480, 704x576, 640x480, 640x360, 352x288, 320x240 | |||
| • Note: | |||
| If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. | |||
| Bit Rate Control | CBR, VBR | ||
| Video Compression | • Main Stream: H.265+/H.265/H.264+/H.264 | ||
| • Sub-Stream: H.265/H.264 | |||
| H.264 Type | High Profile | ||
| H.264+ | Main Stream Supported | ||
| H.265 Type | Main Profile* | ||
| H.265+ | Main Stream Supported* | ||
| Video Bit Rate | • Main Stream: 256 Kbps to 6 Mbps | ||
| • Sub-Stream: 64 Kbps to 512 Kbps | |||
| Image | |||
| Image Settings | • Mirror | ||
| • Brightness | |||
| • Contrast | |||
| • Saturation | |||
| • Sharpness | |||
| • Exposure | |||
| • WDR | |||
| • White Balance | |||
| • Prevent Overexposure to Infrared Light | |||
| • HLC Adjustable by Client Software | |||
| Image Enhancement | BLC/3D DNR/HLC/SmartIR | ||
| Wide Dynamic Range | 120 dB | ||
| Note: When People & Vehicle Analytics is enabled, only DWDR is supported. | |||
| SNR | ? 52 dB | ||
| Image Parameters Switch | Yes | ||
| Privacy Mask | Up to 4 Masks | ||
| ROI | 1 Region | ||
| OSD Setting | Yes<
