Leírás és Paraméterek
| Kamera | ||
| Képérzékelő | 1/3” Progressive Scan CMOS | |
| Shutter Speed | 1/3 to 1/10000 s | |
| Slow Shutter | Yes | |
| Aperture | 4 mm: F1.6 | |
| Optika | Fixed focal lens (4 mm) | |
| Lens Mount | M12 | |
| Min. szükséges megvilágítás | 0 lux with IR/white Light | |
| Day/Night Mechanism | IR Cut Filter | |
| Day/Night Switch | Day/Night/Auto/Schedule-Switch | |
| Digital Noise Reduction | 3D DNR | |
| WDR | DWDR | |
| Weatherproof Rating | IP66 | |
| IR Working Distance | 30m | |
| Illumination Distance | 30 m | |
| Látószög | (4mm) Horizontal FOV: 79°, Vertical FOV: 43°, Diagonal FOV: 93° | |
| LENS | ||
| Type | Fixed Focal Lens | |
| Focal Length | 4 mm | |
| Aperture | F1.6 | |
| FOV | Horizontal FOV: 79°, Vertical FOV: 43°, Diagonal FOV: 93° | |
| Lens Mount | M12 | |
| DORI Distance | Detect: 80 m (262 ft) | |
| Observe: 33 m (109 ft) | ||
| Recognize: 16 m (52 ft) | ||
| Identify: 8 m (26 ft) | ||
| Angle Adjustment (Manual) | ||
| Range | Pan: -90° to 90°, | |
| Tilt: -90° to 90° | ||
| ILLUMINATOR | ||
| IR LED | Quantity: 2 | |
| Range: 30m | ||
| Wavelength: 850nm | ||
| White LED | Quantity: 2 | |
| Range: 30m | ||
| Illuminator On/Off Control | Auto/Scheduled/Always on/Always off | |
| VIDEO | ||
| Max. Resolution | 2560 X 1440 | |
| Main Stream | Frame Rate: | |
| 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps | ||
| 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps | ||
| Resolution: | ||
| 2560x1440, 2304x1296, 2048x1280, 1920x1080, 1280x720 | ||
| Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. | ||
| Sub-Stream | Frame Rate: | |
| 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps | ||
| 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps | ||
| Resolution: | ||
| 640x480, 352x288, 320x240 | ||
| Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. | ||
| Bit Rate Control | CBR, VBR | |
| Video Compression | Main Stream: H.265+/H.265/H.264+/H.264 | |
| Sub-Stream: H.265/H.264 | ||
| H.264 Type | Main Profile/High Profile | |
| H.264+ | Main Stream Supported | |
| H.265 Type | Main Profile | |
| H.265+ | Main Stream Supported | |
| Video Bit Rate | Main Stream: 256 Kbps to 4 Mbps | |
| Sub-Stream: 64 Kbps to 512 Kbps | ||
| Image | ||
| Image Settings | Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance Adjustable by Client Software, Rotation(90°/270°) | |
| Image Enhancement | BLC/3D DNR/HLC/SmartIR | |
| Wide Dynamic Range | DWDR | |
| SNR | ? 52 dB | |
| Image Parameters Switch | Yes | |
| Privacy Mask | Up to 4 Masks | |
| ROI | 1 Region | |
| OSD Setting | Yes | |
| Hang | ||
| Hangkommunikáció | Two-Way Audio | |
Hangbemenet
