Leírás és Paraméterek
| Kamera | |
| Képérzékelő | 1/2.7? Progressive Scan CMOS |
| Shutter Speed | 1/3 to 1/10000 s |
| Slow Shutter | Yes |
| Min. szükséges megvilágítás | 0.005 Lux; 0 Lux with IR/White light |
| Day/Night Mechanism | IR Cut Filter |
| Day/Night Switch | Unified/ Scheduled/ Auto |
| LENS | |
| Type | Fixed Focal Lens |
| Focal Length | 2.8/4/6 mm |
| Aperture | F1.6 |
| FOV | ? 2.8 mm: |
| Horizontal FOV: 111.4°, Vertical FOV: 58.8°, Diagonal FOV: 134° | |
| ? 4 mm: | |
| Horizontal FOV: 88°, Vertical FOV: 46°, Diagonal FOV: 105.4° | |
| ? 6 mm: | |
| Horizontal FOV: 57.3°, Vertical FOV: 31.3°, Diagonal FOV: 67.2° | |
| Lens Mount | M12*P 0.5 |
| DORI Distance | ? 2.8 mm |
| Detect: 64 m (210 ft) | |
| Observe: 27 m (89 ft) | |
| Recognize: 13 m (43 ft) | |
| Identify: 6 m (20 ft) | |
| ? 4 mm | |
| Detect: 80 m (262 ft) | |
| Observe: 33 m (108 ft) | |
| Recognize: 16 m (52 ft) | |
| Identify: 8 m (26 ft) | |
| ? 6 mm | |
| Detect: 120 m (394 ft) | |
| Observe: 50 m (164 ft) | |
| Recognize: 24 m (79 ft) | |
| Identify: 12 m (39 ft) | |
| Angle Adjustment (Manual) | |
| Range | Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360° |
| ILLUMINATOR | |
| IR LED | ? Quantity: 2 |
| ? Range: 30m | |
| ? Wavelength: 850nm | |
| White LED | ? Quantity: 2 |
| ? Range: 30m | |
| Illuminator On/Off Control | Auto/Scheduled/Always on/Always off |
| VIDEO | |
| Max. Resolution | 2880 X 1620 |
| Main Stream | ? Frame Rate: |
| 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps | |
| 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps | |
| ? Resolution: | |
| 2880x1620,2688x1520, 2304x1296, 2048x1280, 1920x1080, | |
| 1280x720 | |
| ? Note: | |
| If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. | |
| Sub-Stream | ? Frame Rate: |
| 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps | |
| 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps | |
| ? Resolution: | |
| 704x576,640x480, 352x288, 320x240 | |
| ? Note: | |
| If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. | |
| Bit Rate Control | CBR, VBR |
| Video Compression | ? Main Stream: H.265+/H.265/H.264+/H.264 |
| ? Sub-Stream: H.265/H.264 | |
| H.264 Type | High Profile |
| H.264+ | Main Stream Supported |
| H.265 Type | Main Profile* |
| H.265+ | Main Stream Supported* |
| Video Bit Rate | ? Main Stream: 256 Kbps to 6 Mbps |
| ? Sub-Stream: 64 Kbps to 512 Kbps | |
| Image | |
| Image Settings | ? Mirror |
| ? Brightness | |
| ? Contrast | |
| ? Saturation | |
| ? Sharpness | |
| ? Exposure | |
| ? WDR | |
| ? White Balance | |
| ? Prevent Overexposure to Infrared Light | |
| ? HLC Adjustable by Client Software | |
| Image Enhancement | BLC/3D DNR/HLC/SmartIR |
| Wide Dynamic Range | 120 dB |
| Note: When People & Vehicle Analytics is enabled, only DWDR is supported. | |
| variant | (4MM) |
