Leírás és Paraméterek
| Kamera | |
| Képérzékelő | 1/3” Progressive Scan CMOS |
| Shutter Speed | 1/3 to 1/10000 s |
| Slow Shutter | Yes |
| Aperture | 4 mm: F1.6 |
| Optika | Fixed focal lens (2.8 mm / 4 mm / 6 mm) |
| Lens Mount | M12 |
| Min. szükséges megvilágítás | 0 lux with IR/white Light |
| Day/Night Mechanism | IR Cut Filter |
| Day/Night Switch | Unified/ Scheduled/ Auto |
| Digital Noise Reduction | 3D DNR |
| WDR | DWDR |
| Weatherproof Rating | IP66 |
| IR Working Distance | 30m |
| Forgatási/döntési szög | Pan: 0° to 350°, Tilt: 0° to 120° |
| Illumination Distance | 30 m |
| Látószög | (4mm) Horizontal FOV: 79°, Vertical FOV: 43°, Diagonal FOV: 93° |
| Digitális nagyítás | Yes |
| LENS | |
| Type | Fixed Focal Lens |
| Focal Length | 4 mm |
| Aperture | F1.6 |
| FOV | 4mm: |
| Horizontal FOV: 79°, Vertical FOV: 43°, Diagonal FOV: 93° | |
| Lens Mount | M12 |
| DORI Distance | 4 mm: |
| Detect: 80 m (262 ft) | |
| Observe: 33 m (109 ft) | |
| Recognize: 16 m (52 ft) | |
| Identify: 8 m (26 ft) | |
| PTZ | |
| Pan/tilt Range | Pan: 0° to 350°, Tilt: 0° to 120° |
| Pan/tilt Speed | Pan Speed: |
| Configurable from 1° to 55°/s; Preset Speed: 55°/s | |
| Tilt Speed: | |
| Configurable from 1° to 40°/s, Preset Speed 40°/s | |
| Manual Control Speed | Configurable from 8° to 35°/s |
| Presets | 300 |
| Patrol Scan | 8 patrols, up to 8 presets for each patrol |
| Power-off Memory | Yes; |
| Auto restore to previous PTZ and lens status after power failure | |
| Park Action | Yes; |
| Preset; Patrol Scan | |
| 3D Positioning | Yes |
| Angle Adjustment (Manual) | |
| Range | Pan: 0° to 348° |
| Tilt: 0° to 120° | |
| ILLUMINATOR | |
| IR LED | Quantity: 2 |
| Range: 30m | |
| Wavelength: 850nm | |
| White LED | Quantity: 2 |
| Range: 30m | |
| Illuminator On/Off Control | Auto/Scheduled/Always on/Always off |
| VIDEO | |
| Max. Resolution | 2560 X 1440 |
| Main Stream | Frame Rate: |
| 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps | |
| 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps | |
| Resolution: | |
| 2560x1440, 2304x1296, 2048x1280, 1920x1080 | |
| Sub-Stream | Frame Rate: |
| 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps | |
| 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps | |
| Resolution: | |
| 640x480, 352x288, 320x240 | |
| Bit Rate Control | CBR, VBR |
| Video Compression | Main Stream: H.265+/H.265/H.264+/H.264 |
| Sub-Stream: H.265/H.264 | |
| H.264 Type | Main Profile/High Profile |
| H.264+ | Main Stream Supported |
