| Solar Panel (Photovoltaic Panel) | |
| Power | 90 W |
| Voltage | 18 V |
| Dimensions (L x W x H) | 998×516×30 mm (39.3×20.3×1.2 in) |
| Battery | |
| Type | Lithium |
| Intelligent Auxiliary Heat | Yes |
| Battery Capacity | 31.2 Ah |
| Voltage | 10.8 V |
| Max. Output Voltage | 12.6 V |
| Life | More than 500 cycles |
| Dimension | 242×70×65 mm (9.5×2.8×2.6 in) |
| Charging Condition | • 0°C~45°C |
| • -30°C~45°C (With intelligent auxiliary heating) | |
| Discharging Condition | • -20°C~60°C |
| • -30°C~60°C (With intelligent auxiliary heating) | |
| Angle Adjustment (Manual) | |
| Range | 5°/15°/25°/35°/45°/55° |
| HARDWARE | |
| Interface | • 1× 10/100 Mbps RJ45 |
| • 1× Photovoltaic Panel Connector | |
| • 3× 5.5mm DC Power Plugs (#1, #2: 9V-12.6 VDC/2A, #3: 12 VDC/2A) | |
| Indicator LED | • Quantity: 4 (1× SYS Indicator, 1× LAN Indicator, 1× PV Indicator, 1× BAT Indicator) |
| • Color: Blue | |
| Szoftver jellemzők | |
| Load Control | Yes |
| High and Low Temperature Protection | Yes |
| Overdischarge Protection | Yes |
| Power Consumption Statistics | Yes |
| Displays Real-time Load Status | Yes |
| Battery Level Display | Yes |
| Time Zone Selection | Yes |
| Region Selection | Yes |
| Schedule Saving | Yes |
| Firmware Remote Update | Yes |
| Remote Reboot | Yes |
| Local LAN Management | Yes |
| Smart Charging Control | -30°C~5°C |
| Account Management | Yes |
| Remote Reset | Yes |
| Remote Message Push | Yes |
| Egyéb jellemzők | |
| Tanúsítványok | • CB, PSE (Battery) |
| • CE, FCC, VCCI, IC, IP66 | |
| Csomagolás tartalma | • VIGI SP9030 |
| • Quick Start Guide | |
| • Waterproof Cable Attachments | |
| • Mounting Accessories | |
| Doboz mérete (Sz X Mé X Ma) | 1110×615×225 mm (43.7×24.2×8.9 in) |
| Súly | • Product Weight: 15 kg |
| • Package Weight: 17.5 kg | |
| Környezet | • Operating Temperature: -30°C-60°C (With intelligent auxiliary heating) |
| • Operating Humidity: 10%~90%RH, Non-condensing |
