Leírás és Paraméterek
Ports Type 24 x 10/100Mbps POE port (RJ45) + 1 x Gigabit port (RJ45) + 1 x Gigabit Combo
Standards IEEE802.3, IEEE802.3u, IEEE802.3z, IEEE802.3ab, IEEE802.3x, IEEE802.3af, IEEE802.3at, IEEE802.3az
Switching capacity 8.8 Gbps
Forwarding performance 6.55Mpps
Packet Buffer 4 M bit
MAC 16K
Weight 2.9kg
Dimensions (W×D×H) 440mm x 244.8mm x 44mm
PoE Standard IEEE 802.3af, IEEE 802.3 at
Max.PoE Power Maximum total power: 370W
Maximum PoE power for single port: 30W
PoE Mode ModeA (1236), ModeB (4578)
Power Supply AC: 100 to 240V, 50/60Hz
Max.Power 385W
Prior Ports 1 to 8
Cooling Fans 1
Operating Humidity 5% to 90% RH, noncondensing
Operating Temperature 0°C to 40°C (32°F to 104°F)
Indicator Power:
Steady on: Normal power input
Off: Abnormal power input
PoE:
Off: The PoE port is not supplying power
Steady on: The PoE port is supplying power normally
Link/Act:
Off: Disconnected to the port
On: Connected to the port
Blinking: Transmitting data
MAX:
Off: The total PoE power is less than 80% of the total power of the device
Steady on: The total PoE power is higher than 85% of the total power of the device
